Akasol NeeoSystem Type 4 Lithium Battery Storage Solution 22kWh 48V is listed for TieDex store sale under Lithium-Ion Batteries. The brand/vendor is Akasol. This listing has been prepared with structured product information, clean import fields, image mapping, and SEO-ready content for online selling.

Product Overview

The neeoRACK is an absolute all-rounder among lithium-ion energy storage units. It covers all the requirements of large privates homes just as reliably as more extensive applications since it has a modular design capable of combining several neeoRACKs into one neeoSYSTEM. Key Features: • ​Ideal for large private homes and operators of commercial plants • 10 year warranty (according to our warranty conditions) • 20 year service life (25°C) • 7,000 cycles at 90% DoD and 1C • Safety-tested technology taken from e-mobility • Efficiency up to 98% • Fast-charging • Small footprint • Integrated battery management system (BMS) • Unrestricted partial cycling – no memory effect Technical Specification: Technical specifications of neeoRACK Voltage 2 screw terminals 70 to 95 mm2 Protection class IP 50 Power connection 48 V Operating temperature 0° to 40°C Max. air humidity 85%, non condensing

Name Type 3 Type 4 Type 5 Cell Technology Lithium-ion batteries Lithium-ion batteries Lithium-ion batteries Power 16.5 kWh 22 kWh 27.5 kWh Useful Power 15 kWh 20 kWh 25 kWh Nom. Power (at 25°C) 16.5 kW 22 kW 27.5 kW Max. Power (20 s) 33 kW 33 kW 33 kW Dimensions (w x d x h): 630 × 630 × 1300 mm 630 × 630 × 1900 mm 630 × 630 × 1900 mm Weight Approx. 255 kg 340 kg 395 kg Expandable To – 5 neeoRacks – Recommended For 1-phase operation 1-phase operation 1-phase operation Operating mode 3-phase operation 3-phase operation 3-phase operation

Key Details

• Brand / Vendor: Akasol
• Product SKU: neeosystem type 4
• MPN / Model: neeosystem type 4
• Category: Lithium-Ion Batteries
• Parent Category: Batteries AGM, Gel Lithium, OPZV and OPZS
• Condition: New
• Availability: InStock
